Description
Travel motor assembly (final drive) with reduction gear. Specifications shown are from manufacturer catalog data. Exact configuration confirmed by nameplate before quoting.
| Series models | HM05/06VA · HM07VA · HM08VA · HM090VA · HM10VA · HM15VA · HM18VA · HM22VA |
|---|---|
| Gear ratio | 68.6 (HM05/06VA) · 53.706 (all other models) |
| Theoretical output torque | 570–2,445 kgf·m (model dependent) |
| Displacement | 27.5–82.8 cc/rev (model dependent) |
| Max. motor speed | 3,200–3,900 rpm (model dependent) |
| Max. pressure | 250–350 kg/cm² (model dependent) |
| Application class | 4–15 ton (model dependent) |
| Manufacturer | Handok Hydraulic |
| Country of origin | South Korea |
Manufacturer catalog image of this travel motor model shown. Photos of the exact unit are available on request — send a photo of your motor nameplate with your enquiry and we match the variant.
